Pierce Arrow  2006-2  Specifications 21 march 2006

Length - 27'2" feet Width - 38 inches
Height @ canopy top - 48 inches
Weight (approx) - 2350 pounds
Coefficient of drag Cd (estimated) - .24
Frontal area in sq. ft. - 11.9
Engine type - 3.9-4.26 liter Cummins Special Duty Diesel
450hp. 750hp w/N2o
(Note) Turbochargers and any fuel allowed including
nitrous oxide in Diesel Streamliner class
Class (E/DSL) Present land speed record open
Horsepower required (based on RSR Aero-horsepower calculator)
200 mph (325km) = 182 225 mph (365 km) = 256
250 mph (405 km) = 350 275 mph (446km) = 463
301 mph (488km) = 610




ide canopy for crew work area s
